Manufacturer: SENECA
Type: On/Off Sensor Digital Amplifier , single channel
Model: Z112A
Power supply:
19 … 28 VAC
19 … 40 VDC
Frequency: 50/60 HZ
Max power consumption: 2.5 W
Input: free contact, npn/pnp 2-3 wire, 24 Vdc
Output: 1 relay SPDT changeover, 5 A, 250 Vac /1 A, 30 Vdc
Dimensions (b x h x d): 17.5 x 100 x 112 mm
Operating temp.: 0 … + 50 °C
