Manufacturer: ifm

Type: INDUCTIVE SENSOR

Part No.: II0005

MRN: II-2010-ABOA

Sensing Range: 10 mm

Real Sensing Range: 10 ± 10% mm

Operating Distance: 0 … 8.1 mm

Operating Voltage: 20 … 250 V AC/DC, 45 … 65 Hz for AC

Voltage Drop AC, max.: 6.5 V AC

Voltage Drop DC max.: 6 V DC

Switching Output Current AC: 250 mA AC, 350 mA AC at 50 °C

Switching Output Current DC: 100 mA DC

Switching Frequency: 25Hz (AC), 50Hz (DC)

Output Function: Normally Open

Connector Type, Length: PVC Cable, 2 m

Protection Class: II

Enclosure Rating: IP67

Housing: Threaded type

Ambient Operating Temperature: -25 … 80°C

Diameter, Housing Length: 30. 81 mm

Material: PBT

Mounting: Flush- Mountable

Weight: 182.5 g
