Manufacturer: PEPPERL FUCHS

Type: ULTRASONIC SENSOR

Model No.: UB2000F54IV15

Part No.: 108162

Sensing range: 80 … 2000 mm

Adjustment range: 100 … 2000 mm

Dead band: 0 … 80 mm

Standard pate: 100 x 100 mm

Response delay: ≤ 150 ms

Operating Voltage: 10 … 30 V DC

Operating Current: 4 … 20 mA

Transducer frequency: 175 KHz

Electrical design: PNP

Switching output: Analog output, 4 … 20 mA

Input type: A1-level: -UB…+1 V,A2-level: +4 V…+UB

Output type: evaluation limit A1: 100 mm evaluation limit A2: 2000 mm

Connector type: M12 Connector, 5-pin

Protection class: II

Enclosure rating: IP65

Ambient Operating temperature: -25 … 70°C

Dimensions: 32 x 24 x 105 mm

Weight: 100 g

Housing material: ABS

Sensing face material: epoxy resin/hollow glass sphere mixture; polyurethane foam

Condition: New
