SICK WT250-S162 Background Suppression Sensor

The SICK WT250S162 is a high-performance background suppression sensor designed for accurate object detection in industrial environments. With its reliable sensing range and robust housing, it ensures precision and durability even in demanding conditions.

Manufacturer: SICK
Type: Background Suppression Sensor
Model: WT250-S162
Part No.: 6010707

Technical Information

• Sensing Range: 150 / 500 mm
• Type of Light: Visible Red Light
• Light Source: Pin-Point LED
• Wave Length: 650 nm
• Light Spot Size (Distance): Ø 35 mm (500 mm)
• Housing Design (Light Emission): Rectangular
• Focus Dispersion Angle: 3°
• Supply Voltage: 12 / 240 V AC/DC
• Power Consumption Max.: 2 VA
• Switching Output: Change-Over (CO) (Relay, Electrically Isolated)
• Switching Current: 3 A
• Connection Type: Cable, 5-Wire, 2 m
• Switching Mode: Light Switching
• Housing Material: Plastic, ABS
• Protection Class: IP67
• Operating Temperature: -25 … 55 °C
• Dimensions: 60 x 20 x 43 mm
