Wenglor CP35MHT80 Laser Distance Sensor

The Wenglor CP35MHT80 is a precision laser distance sensor designed for accurate measurement in industrial environments. With a compact design, reliable performance, and advanced measuring technology, it ensures dependable operation across a wide range of applications.

Manufacturer: Wenglor
Type: Laser Distance Sensor
Model: CP35MHT80

Technical Information

• Working Range: 50 … 350 mm
• Measuring Range: 300 mm
• Light Source: Laser (red)
• Wavelength: 660 nm
• Supply Voltage: 18 … 30 V DC
• Current Consumption (Ub = 24 V): < 80 mA
• Measuring Rate: 800 /s
• Temperature Range: -25 … 50 °C
• Analog Output: 0…10 V
• Load Current Voltage Output: < 1 mA
• Current Output Load Resistance: < 500 Ohm
• Interface: RS-232
• Housing Material: Plastic, ABS / Plastic, PC
• Optic Cover: Plastic, PMMA
• Degree of Protection: IP67
• Connection: M12 × 1; 8-pin
