SIEMENS 1FK7 032-5AK71-1SB0 SYNCHRONOUS SERVO MOTOR
The Siemens 1FK7 032-5AK71-1SB0 is a compact, high-performance synchronous servo motor engineered for precise control and rapid acceleration in demanding automation systems. With IP55 protection and thermal class F, it ensures reliable operation in industrial environments.
Manufacturer: Siemens
Type: Synchronous Servo Motor
Model: 1FK7 032-5AK71-1SB0
Part No.: DN645 5414 01 001
Technical Information
- Rated Voltage: 270 V
- Rated Current: 1.3 A
- Stall Current: 1.7 A
- Rated Speed: 6000 min-1
- Max. Speed: 10000 min-1
- Rated Torque: 0.8 Nm
- Stall Torque: 1.15 Nm
- Brake Voltage: 24 VDC
- Brake Power: 7.5 W
- Brake Model: 3001811
- Thermal Class: F
- Mounting Position: B20
- Protection Class: IP55
