SIEMENS 1FT6034-1AK71-3EG1 SYNCHRONOUS SERVO MOTOR
Designed for high-speed precision control, the Siemens 1FT6034-1AK71-3EG1 Synchronous Servo Motor offers dynamic performance and exceptional reliability. Ideal for automation systems and motion control tasks in demanding industrial environments.
Manufacturer: Siemens
Type: Synchronous Servo Motor
Model: 1FT6034-1AK71-3EG1
No YF: T734 3694 01 002
Technical Information
- Stall Torque: 2 Nm
- Rated Torque: 1.3 Nm
- Stall Current: 2.6 A
- Rated Current: 1.9 A
- Rated Speed: 6000 RPM
- Maximum Speed: 9700 RPM
- Protection Class (IP): IP65
- Insulation Class: F
- Encoder: A-2048
