SIEMENS SERVOMOTOR

The Siemens Servomotor (Model: 1FT7105-5AF71-1FB4, Part No: C332 5756 04 001) offers high precision and performance for industrial automation applications. With a rated torque of 28 Nm and a maximum speed of 6000 min^-1, this servomotor is designed for demanding applications requiring robust power delivery and fast response times. It is equipped with a high-performance encoder and brake power for optimized operation.

Manufacturer: Siemens

Type: Servomotor

Model: 1FT7105-5AF71-1FB4

Part No.: C332 5756 04 001

Technical Specifications

• Rated Current [A]: 15
• Stall Current [A]: 26
• Rated Torque [Nm]: 28
• Stall Torque [Nm]: 50
• Rated Voltage [V]: 375
• Rated Speed [min^-1]: 3000
• Max. Speed [min^-1]: 6000
• Protection Class [IP]: 65
• Thermal Class: F
• Encoder: AM22DQ A45
• Brake Voltage [Vdc]: 24
• Brake Power [W]: 36.5
