Siemens 1FT7108-5AB71-1DG0-Z Servomotor (3 Phase)

The Siemens 1FT7108-5AB71-1DG0-Z Servomotor is a compact, high-performance motor designed for a range of industrial applications. It offers precise control, high torque, and efficiency, making it ideal for demanding operations.

Manufacturer: Siemens

Model: 1FT7108-5AB71-1DG0-Z

Type: Servomotor (3 Phase)

Part No.: YF K5645 9090 01 001

Technical Information:

• Motor Type: Compact
• Shaft Height: 100 mm
• Cooling: Natural cooling
• Number of Poles: 10
• Rated Voltage: 363 V
• Rated Torque: 61 Nm
• Static Torque: 70 Nm
• Stall Current: 18 A
• Rated Current: 16 A
• Rated Speed: 1500 rpm
• Maximum Speed: 6000 rpm
• Rotor Moment of Inertia: 248.00 kgcm²
• Temperature Monitoring: Pt1000 temperature sensor
• Protection Class: IP 64
• Thermal Class: F
• Sensor Design Encoder: IC22DQ I35
