SIEMENS 3RH19 11-1GA22 AUXILIARY SWITCH

The Siemens 3RH19 11-1GA22 is a compact and reliable auxiliary switch designed for integration with contactor relays and power contactors. Engineered for high-performance switching operations, it supports robust insulation and surge protection, ensuring dependable functionality in industrial environments.

Manufacturer: Siemens
Type: Auxiliary Switch
Model: 3RH19 11-1GA22
SN: 4011209 276406

Technical Information

• Insulation Voltage (Ui): 690 V
• Operating Current: 10 A
• Surge Voltage Resistance: 6 kV
• Auxiliary Contacts: 2 NO + 2 NC
• Mounting Type: Snap-on mounting
• Electrical Connection: Screw-type terminals
• Suitability: Contactor relay and power contactor
• Operating Temperature: -25 / +60 °C
• Degree of Protection: IP20
• Dimensions: 36.5 x 37.5 x 41.5 mm
