Manufacturer: SIEMENS
Type: Thermal Overload Relay
Model: 3RU1116-1AB0

Brand Name: SIRIUS
Used For: Contactor Mounting
Rated Current: 1.1 … 1.6
Rated Operating Voltage: 690 V AC
Power Loss: 6.6 W
Frequency Rated Value: 50 … 60 Hz
Contact: 1 Normally Open (NO) + 1 Normally Closed (NC)
Number of Poles: 3 Poles
Contactor Mounting Main Circuit: Screw-Type Terminals
Protection Proof: IP20
Operation Temperature: -20 … 70 °C
Dimensions: 87 x 45 x 78 mm
