Siemens Sirius Safety Relay 3TK2834-1BB40
The Siemens Sirius Safety Relay 3TK2834-1BB40 is designed for use in industrial automation to ensure safe and reliable operation of machinery and systems. With a rated insulation voltage of 300 V, this relay ensures safety in circuits requiring a secure electrical connection. The thermal current of the switching element is 6 A, providing efficient power handling capabilities.
With a maximum cable resistance of 30 Ω, this safety relay ensures effective performance while minimizing energy loss. The screw-type terminals offer a reliable electrical connection, simplifying installation and maintenance, while the relay is designed for both screw and snap-on mounting, providing flexibility in installation.
Built to withstand harsh conditions, the 3TK2834-1BB40 safety relay has an IP20 protection class, offering protection against dust and environmental factors. The device operates in a temperature range of -25°C to 60°C, ensuring its reliability in both cold and warm environments.
Manufacturer: Siemens
Type: Sirius Safety Relay
Model: 3TK2834-1BB40
Technical Information:
- Insulation Voltage Rated Value: 300 V
- Thermal Current of the Switching Element: 6 A
- Resistance of the Cable Maximum DC: 30 Ω
- Type of Electrical Connection: Screw-type terminals
- Mounting Type: Screw and snap-on mounting
- Protection Class (IP): IP20
- Ambient Temperature During Operation: -25 … 60 °C
- Dimensions (H x W x D): 138.5 x 44.8 x 120 mm
The Siemens Sirius Safety Relay 3TK2834-1BB40 ensures optimal performance and safety in automation systems, meeting the stringent safety standards of modern industrial environments.
