SIEMENS SIMATIC S5 6ES5431-8MA11 DIGITAL INPUT MODULE

The Siemens 6ES5431-8MA11 is a reliable digital input module from the SIMATIC S5 family, engineered to support a wide range of programmable logic controllers such as the S5-90U, S5-95U, S5-100U, ET 100U, and ET 200U. This 24V DC input module is built for durability and consistent signal processing in industrial environments.

Manufacturer: Siemens
Type: Digital Input Module
Family: SIMATIC S5
Model: 6ES5431-8MA11
Serial No.: C-P1F61707
E Stand: 02
Compatible With: S5-90U / S5-95U / S5-100U, ET 100U, ET 200U

Technical Information

• Number of Inputs: 8
• Input Voltage: 24V DC
• Input Current at “1” Signal: 8.7 mA (at 24 V)
• Current Consumption: 32 mA
• Power Loss: 2 W
• Dimensions: 135 x 85 x 46 mm
