SIEMENS 6ES7136-6BA00-0CA0 DIGITAL INPUT MODULE
The Siemens 6ES7136-6BA00-0CA0 is a high-performance digital input module designed for the ET 200SP series within the SIMATIC DP family. Engineered for reliability and flexibility, this module provides 8 digital inputs with precision signal detection, ideal for advanced industrial automation systems.
Manufacturer: Siemens
Type: Digital Input Module
Model: 6ES7136-6BA00-0CA0
Product Type Designation: ET 200SP
Family: SIMATIC DP
Ref No.: C-P3LE7334 / 06 / V1.0.7 / 423
Technical Information
- Supply Rated Voltage: 24 V DC
- Current Consumption: 75 mA Without Load
- Number of Encoder Supply Output: 8
- Number of Digital Input: 8
- Digital Input Voltage: Signal (0): -30 / 5 V, Signal (1): 15 / 30 V
- Digital Input Current: Signal (1): 3.7 mA
- Operating Temperature: Vertical: 0 / 50 °C, Horizontal: 0 / 60 °C
- Dimensions: 15 x 73 x 58 mm
