SIEMENS 6FX5002-5DG32-1CA0 POWER CABLE PREASSEMBLED

The Siemens 6FX5002-5DG32-1CA0 Power Cable is a preassembled, high-performance connection solution designed for reliable energy and signal transmission in industrial environments. Built with braking lead, reinforced insulation, and SPEED-CONNECT connectors, it ensures safe, efficient, and durable operations.

Manufacturer: Siemens
Type: Power Cable Preassembled
Model: 6FX5002-5DG32-1CA0
Serial No.: IT JS8620250805001

Technical Information

• Length: 20 m
• No. of Cores x Cross-Section: 4×2.5 + 2×1.5C C
• Test Voltage, RMS Power Conductors: 4.0 kV
• Test Voltage, RMS Signal Conductors: 2.0 kV
• Type with Braking Lead: Yes
• Rated Voltage: 500 V
• Connection Cable Engine Side: Connector SPEED-CONNECT
• Connector Size: 1.5 / M40
• Material of Cable Sheath: PVC, DESINA Color Orange RAL 2003
• Operation Temperature Range: -20 / 80 °C
• Smallest Bending Radius (Flexible in Cable Carriers): 225 mm
• Travel Path: 5 m
