SIEMENS RXL39.1/FC-13 ROOM CONTROLLER

The Siemens RXL39.1/FC-13 is a high-quality room controller designed for reliable performance in building automation systems. It ensures precise control and energy-efficient operation for fan coil units, ceiling voids, and panel-mounted applications.

Manufacturer: Siemens
Type: Room Controller
Model: RXL39.1/FC-13
Part No.: S55373-C122
Serial No.: S 160225A
Ref No.: 160225A 11595

Technical Information

• Operating Voltage: 230 V AC
• Frequency: 50/60 Hz
• Power Consumption: max. 12 VA
• Contact Voltage: 16 VDC
• Contact Current: 5 mA
• Output Current: 1.5 mA

Mounting

• DIN rail, for screw fixing
• Suitable for ceiling voids with cover, fan coil units, and panels

Protection & Dimensions

• Degree of Protection: IP20
• Dimensions (W x H x D): 152 x 120 x 62 mm
