SIEMENS SQL33.03 ELECTROMOTORIC ACTUATOR

The Siemens SQL33.03 is a robust electromotoric actuator engineered for precise control in HVAC and automation systems. With a reliable 3-position signal and fast 30-second actuation, it delivers efficient and accurate positioning for demanding applications.

Manufacturer: SIEMENS
Type: Electromotoric actuator
Model: SQL33.03
Part No.: 060329C

Technical Information

• Housing Material: Die-cast aluminium
• Cover Material: Plastic
• Operating Voltage: AC 230 V
• Positioning Signal: 3-position
• Positioning Time: 30 s
• Angular Rotation: 90°
• Torque: 10 Nm
• Power Consumption: 6.5 VA
• Degree of Protection: IP44
• Ambient Temperature (Operation): -15 / 55 °C
