SKF 1208 ETN9/C3 Self-Aligning Ball Bearing
The SKF 1208 ETN9/C3 Self-Aligning Ball Bearing is designed to accommodate misalignment while maintaining smooth and efficient operation. Featuring a TN9 glass fiber reinforced PA66 cage and C3 radial internal clearance, this bearing offers superior durability and high-speed capability.
Manufacturer: SKF
Type: SELF-ALIGNING BALL BEARING
Model: 1208 ETN9/C3
Technical Information:
- Bore Diameter (d): 40 mm
- Outer Diameter (D): 80 mm
- Width: 18 mm
- Dynamic Load Rating: 19.9 kN
- Static Load Rating: 6.95 kN
- Fatigue Load Limit: 0.355 kN
- Limiting Speed: 11000 RPM
- Reference Speed: 18000 RPM
- Cage: TN9, Glass fiber reinforced PA66 cage, rolling element centered
- Radial Internal Clearance: C3
With its self-aligning design, this bearing is well-suited for applications where shaft misalignment may occur, ensuring long-lasting performance and reduced operational wear.
