SKF 1219 K Self-Aligning Ball Bearing
The SKF 1219 K Self-Aligning Ball Bearing is engineered for high-performance applications requiring accommodation of misalignment and smooth rotation. With a tapered bore design and sheet metal cage, this bearing provides durability and efficiency in industrial and machinery applications.
- Manufacturer: SKF
- Type: Self-Aligning Ball Bearing
- Model: 1219 K
Technical Information
- Bore Diameter (d): 95 mm
- Outer Diameter (D): 170 mm
- Width (B): 32 mm
- Basic Dynamic Load Rating: 63.7 kN
- Basic Static Load Rating: 27 kN
- Reference Speed: 8,000 r/min
- Limiting Speed: 5,000 r/min
- Fatigue Load Limit: 1.2 kN
- Bore Type: K, Tapered 1:12
- Cage: Sheet Metal
