SKF 2303 Self-Aligning Ball Bearing
The SKF 2303 Self-Aligning Ball Bearing is engineered for applications where misalignment or shaft deflection is an issue. With a robust sheet metal cage, high-speed capabilities, and precise load ratings, it ensures smooth operation and extended bearing life even under dynamic conditions.
Manufacturer: SKF
Type: Self-Aligning Ball Bearing
Model: 2303
Technical Information:
- Bore Diameter (d): 17 mm
- Outer Diameter (D): 47 mm
- Width (B): 19 mm
- Dynamic Load Rating (Cr): 14.3 kN
- Static Load Rating (C0r): 3.55 kN
- Fatigue Load Rating: 0.183 kN
- Limiting Speed: 22,000 r/min
- Reference Speed: 30,000 r/min
- Cage Type: Sheet Metal
