SKF 2306 M Self-Aligning Ball Bearing
The SKF 2306 M Self-Aligning Ball Bearing is designed to accommodate misalignment and shaft deflection, making it ideal for demanding industrial applications. With a durable brass cage, high-speed ratings, and excellent load handling capabilities, this bearing ensures stable and efficient performance.
Manufacturer: SKF
Type: Self-Aligning Ball Bearing
Model: 2306 M
Technical Information:
- Bore Diameter (d): 30 mm
- Outer Diameter (D): 72 mm
- Width (B): 27 mm
- Dynamic Load Rating (Cr): 31.2 kN
- Static Load Rating (C0r): 8.8 kN
- Fatigue Load Limit: 0.45 kN
- Limiting Speed: 13,000 r/min
- Reference Speed: 18,000 r/min
- Cage: Brass
