SKF 2308 K C3 Self-Aligning Ball Bearing

The SKF 2308 K C3 is a premium self-aligning ball bearing engineered for applications where shaft misalignment may occur. It features a C3 radial internal clearance, allowing for greater flexibility in high-speed or high-load operations. With a K-type tapered bore (1:12), this bearing is ideal for precision fit and easy mounting in industrial machinery.

Manufacturer: SKF

Type: Self-Aligning Ball Bearing

Model: 2308 K C3

Technical Information:

• Bore Diameter (d): 40 mm
• Outer Diameter (D): 90 mm
• Width (B): 33 mm
• Dynamic Load Rating (Cr): 54000 N
• Static Load Rating (C0r): 16000 N
• Limiting Speed: 10000 rpm
• Reference Speed: 14000 rpm
• Radial Internal Clearance: C3
• Bore Type: K (Tapered 1:12)
