SKF 2309 EKTN9 Self-Aligning Ball Bearing

The SKF 2309 EKTN9 Self-Aligning Ball Bearing is designed for applications where misalignment is unavoidable. Its self-aligning feature, tapered bore, and high-speed capability make it ideal for demanding environments. The TN9 cage, made of glass fibre reinforced nylon, ensures smooth operation and durability.

Manufacturer: SKF

Type: Self-Aligning Ball Bearing

Model: 2309 EKTN9

Technical Information:

• Bore Diameter (d): 45 mm
• Outer Diameter (D): 100 mm
• Width: 36 mm
• Dynamic Load Rating: 63.7 kN
• Static Load Rating: 19.3 kN
• Fatigue Load Limit: 1 kN
• Limiting Speed: 13000 RPM
• Reference Speed: 9000 RPM
• Bore Type: K, Tapered 1:12
• Cage: TN9, Nylon Glass Fibre Filled Cage
