SKF 61880 MA/C3 Deep Groove Ball Bearing
The SKF 61880 MA/C3 is a high-precision deep groove ball bearing designed for heavy-duty applications requiring high load capacity, reduced friction, and stable performance at elevated speeds. It features a machined brass cage and increased internal clearance for optimal reliability.
Manufacturer: SKF
Type: Deep Groove Ball Bearing
Model: 61880 MA/C3
Technical Information
- Bore Diameter: 400 mm
- Outer Diameter: 500 mm
- Width: 46 mm
- Dynamic Load Rating (Cr): 247 kN
- Static Load Rating (C0r): 405 kN
- Fatigue Load Rating: 8.15 kN
- Limiting Speed: 1900 rpm
- Reference Speed: 2400 rpm
- Cage: MA machined brass cage, outer ring centred
- Clearance: C3
