SKF PTFE Composite Thrust Washer PCMW142601.5E
The SKF PCMW142601.5E is a high-quality PTFE composite thrust washer engineered for applications requiring low friction and high wear resistance. Designed for axial load support, this washer ensures smooth operation and long service life in various mechanical and industrial systems. Its PTFE composite material provides excellent sliding properties and maintenance-free performance.
- Manufacturer: SKF
- Type: PTFE Composite Thrust Washer
- Model: PCMW142601.5E
Technical Information
- Bore Diameter (d): 14 mm
- Outer Diameter (D): 26 mm
- Thickness (H): 1.5 mm
- Pitch Diameter of Attachment Bolt Holes (J): 20 mm
- Diameter Fixing Bore (K): 2.25 mm
- Basic Dynamic Load Rating: 30 kN
- Basic Static Load Rating: 93 kN
- Material: PTFE Composite
- No. of Items/Set: 10
