Manufacturer: SKF

Type: Insert bearing with set screw locking and extended inner ring

Model: YAR208-2F

Bore Diameter d: 40 mm

Outer diameter D: 80 mm

Width of inner ring B: 49.2 mm

Width of outer ring C: 21 mm

Basic load ratings:

Dynamic C: 30700 N

Static C₀: 19000 N

Fatigue load rating: 800 N

Limiting speed: 4800 rpm

Inner ring extension: on both sides

Outer ring type: Spherical

Retaining feature, inner ring: Set screws

Sealing: Seal and flinger on both sides

Bore type: Cylindrical
