Manufacturer: SKF
Type: Insert bearing with set screw locking and extended inner ring
Model: YAR207-2F
Bore Diameter d: 35 mm
Outer diameter D: 72 mm
Width of inner ring B: 42.9 mm
Width of outer ring C: 19 mm
Width, total: 42.9 mm
Basic load ratings:
Dynamic C: 25500 N
Static C0: 15300 N
Fatigue load rating: 6550 N
Limiting speed: 5300 rpm
Inner ring extension: on both sides
Outer ring type: Spherical
Retaining feature, inner ring: Set screws
Sealing: Seal and flinger on both sides
Bore type: Cylindrical
Lubricant: Grease
