Manufacturer: SKF
Type: Insert bearing with an eccentric locking collar and extended inner ring
Model: YEL209-2F
Bore Diameter d: 45 mm
Outer diameter D: 85 mm
Width of inner ring B: 42.8 mm
Width of outer ring C: 22 mm
Basic load ratings:
Dynamic C: 33200 N
Static C0: 21600 N
Fatigue load rating: 915 N
Limiting speed: 4300 rpm
Inner ring extension: On both sides
Outer ring type: Spherical
Retaining feature, inner ring: Eccentric collar
Sealing: Seal and flinger on both sides
Bore type: Cylindrical
