Manufacturer: SKF
Type: Insert bearing with an eccentric locking collar and extended inner ring
Model: YEL 211 2F
Bore Diameter d: 55 mm
Outer diameter D: 100 mm
Width of inner ring B: 55.6 mm
Width of outer ring C: 25 mm
Width of outer ring B1: 71.4 mm
Basic load ratings:
Dynamic C: 43.6 kN
Static C0: 29 kN
Fatigue load rating: 1.25 kN
Limiting speed: 3600 rpm
Inner ring extension: on both sides
Outer ring type: Spherical
Retaining feature, inner ring: Eccentric collar
Sealing: Seal and flinger on both sides
Bore type: Cylindrical
