SNR 1209.K.J30 Self-Aligning Ball Bearing
The SNR 1209.K.J30 Self-Aligning Ball Bearing is designed for applications requiring automatic self-alignment to compensate for shaft misalignment. With high dynamic and static load ratings, this bearing ensures durability and stability in various industrial applications.
Manufacturer: SNR
Type: SELF-ALIGNING BALL BEARING
Model: 1209.K.J30
Technical Information:
- Bore Diameter (d): 45 mm
- Outer Diameter (D): 85 mm
- Width (B): 19 mm
- Dynamic Load Rating: 21.5 kN
- Static Load Rating: 7.3 kN
- Reference Thermal Speed: 8100 tr/min
- Mechanical Limit Speed: 11000 tr/min
- Radial Internal Clearance: J30
This self-aligning ball bearing offers reliable operation, high-speed performance, and the ability to compensate for shaft misalignments, making it an excellent choice for demanding applications.
