SNR Self-Aligning Ball Bearing 2205 EEG15

The SNR 2205 EEG15 Self-Aligning Ball Bearing is designed for high precision and efficiency, ideal for applications that require alignment compensation. It features a polyamide cage and robust dynamic and static load ratings.

Manufacturer: SNR

Model: 2205 EEG15

Type: Self-Aligning Ball Bearing

Technical Information:

• Bore Diameter (d): 25 mm
• Outer Diameter (D): 52 mm
• Width: 18 mm
• Minimum Chamfer Dimension (rs min): 1 mm
• Dynamic Load Rating (Ca): 12.1 kN
• Static Load Rating (C0a): 3.3 kN
• Fatigue Limit Load: 0.15 kN
• Mechanical Limit Speed: 8000 tr/min
• Cage: G15, Polyamide Cage
