SNR 2206 EEG15 Self-Aligning Ball Bearing
The SNR 2206 EEG15 Self-Aligning Ball Bearing is designed to handle radial loads while accommodating misalignment, offering high performance and durability for industrial applications.
Manufacturer: SNR
Model: 2206 EEG15
Type: Self-Aligning Ball Bearing
Technical Information:
- Bore Diameter (d): 30 mm
- Outer Diameter (D): 62 mm
- Width: 20 mm
- Minimum Chamfer Dimension (rs min): 1 mm
- Dynamic Load Rating (Ca): 15.7 kN
- Static Load Rating (C0a): 4.65 kN
- Fatigue Limit Load: 0.21 kN
- Mechanical Limit Speed: 6500 tr/min
- Cage: G15, Polyamide cage
