ST HCF4049UBE Integrated Chip
The ST HCF4049UBE is a CMOS buffer and converter integrated circuit designed for efficient signal processing in industrial and electronic applications. It delivers low power consumption with reliable inverting logic functions, making it suitable for a wide range of control and interface systems.
Manufacturer: ST
Type: Integrated Chip
Model: HCF4049UBE
Part No.: 98949Y
Technical Information
- Supply Voltage: 3 / 15 V
- Typical Quiescent Current: 0.02 mA
- Maximum Power Dissipation: 200 mW
- Logic Function: Buffer/Converter
- Number of Channels per Chip: 6
- Polarity: Inverting
- Absolute Propagation Delay Time: 120 ns
- Process Technology: CMOS
- Input Signal Type: Single-Ended
- Lead Shape: Through Hole
- No. of Pins: 16
- Maximum Low Level Output Current: 28 mA Min
- Maximum High Level Output Current: -4.5 mA Min
- Mounting: Through Hole
- Operating Temperature: -40 / 85°C
