Steyr 2307 Self-Aligning Ball Bearing
The Steyr 2307 Self-Aligning Ball Bearing is engineered for applications where shaft misalignment may occur. It features a dual-row design that provides excellent performance under radial loads and moderate axial loads. With high-speed capability and robust load ratings, it is ideal for demanding industrial environments.
Manufacturer: Steyr
Type: Self-Aligning Ball Bearing
Model: 2307
Technical Information:
- Bore Diameter (d): 35 mm
- Outer Diameter (D): 80 mm
- Width (B): 31 mm
- Dynamic Load Rating (Cr): 39100 N
- Static Load Rating (C0r): 11000 N
- Limiting Speed (Grease): 12300 rpm
- Limiting Speed (Oil): 15700 rpm
