Manufacturer: STM
Type: Reflective Beam Sensor
Model: RLV74VS81BHP
Part No.: 44544

Sensing Range: 8 … 20 mm
Light Type: Infrared 880 nm
Operating Voltage: 10 … 30 V DC
Current Consumption: 30 mA
Switching Function: Light-On
Electrical Connection: Connector M8, 3-Pin
Material: Nickel-Plated Brass
Protection Class: IP65
Operating Temperature: -10 … 55 °C
Dimensions: 59 x 14 x 8 mm
