SUNON DP200A AXIAL FAN

Axial Fan

Sunon DP200A Axial Fan features a 119x119x38 mm square frame and 5 blades, offering up to 198.64 m3/h flow rate and 0.39 inch-H20 static pressure, designed for high-efficiency air circulation in industrial applications.

SKU: 1063782 Category: Tags: , , , , , , , , , , , , ,
In stock: 1 pcs
Very low
Hurry! Only 1 left in stock.
Add to quote

Sunon DP200A Axial Fan

The Sunon DP200A Axial Fan is a high-performance fan designed for effective air circulation in industrial systems. With a square frame and 5 blades, it provides reliable airflow at various speeds and power ratings for optimal cooling.

Manufacturer: Sunon

Model: DP200A

Type: Axial Fan

Part No.: 2123XBL.GN

Technical Information:

  • Frame Shape: Square Frame
  • No. of Blades: 5
  • Dimensions (mm): 119x119x38
  • Direction: Push
  • Bearing: VAPO
  • Voltages (V AC): 220 to 240
  • Power Rating (W): 22/21
  • Speed (rpm): 2850/3150
  • Flow Rate (m3/h): 164.69/198.64
  • Flow Rate (CFM): 97/117
  • Current (A): 0.14/0.12
  • Frequency (Hz): 50/60
  • Inverter: Without Inverter
  • Number of Wires: 2
  • Blade Material / Fan Housing Material: Plastic / Metal
  • Static Pressure (inch-H20): 0.34/0.39
Weight0,53 kg
