Manufacturer: TAKEX / SEEKA
Type: Convergent reflective Photoelectric Sensor
Model: GSZ3RSPN
Part No.: 107Y

Detection method: Convergent reflective
Detecting distance: 3 … 30 mm
Detection object: Opaque, translucent, transparent
Power supply: 12 … 24 V DC (Brown), 0 V (Blue)
Current consumption: 20 mA (max)
Control output: PNP open collector
Operation mode: Light-ON/Dark-ON selectable
Response time: 0.35 ms (max)
Hysteresis: 10% (max)
Light source (wave length): Red LED (645 nm)
LED Indicator: Operation (red), Stability (green)
Connection: Cable (outer diameter: 3 mm; length 2m)
Protection Class: IP67
Ambient light: Withstand 5,000 lx (max)
Ambient temperature: -25 … +55° C
