TECUMSEH TAG4546Z COMPRESSOR
Designed for high-efficiency refrigeration applications, the Tecumseh TAG4546Z is a robust three-phase compressor that supports R404A refrigerant. With a high displacement capacity and wide ambient temperature tolerance, it ensures consistent cooling performance in industrial environments.
Manufacturer: Tecumseh
Type: Compressor
Model: TAG4546Z
Part No.: 6835631100 / 54A2418 B0 050 111 C
Phase: 3~ Three Phase
Technical Information
- Rated Voltage [V]: 400/440
- Displacement [cm³]: 90.2
- Oil Charge [cm³]: 1960
- Ambient Temperature [°C]: -35 to +46
- LRA: 42.5
- Pressure: 20.1 to 22.1 bar
- Frequency [Hz]: 50/60
- Refrigerant: R404A
