Manufacturer: TELEMECANIQUE
Type: Thermal Overload Relay
Model: LRD07
Part No.: 034677

Short Name: LRD
Rated Operational Voltage: 600 V AC
Rated Operational Current: 5 A
Rated Insulation Voltage: 690 V AC
Frequency: 50 … 60 Hz
Sitting Range: 1.6 … 2.5 A
Rated Impulse Voltage (Uimp): 6 kV
Poles No.: 4-Pole
Auxiliary Contact: 2 Normally Open (NO) + 2 Normally Closed (NC)
Protection Class: IP20
Ambient Temperature: -20 … 60 °C
Dimensions: 66 x 45 x 70 mm
