Manufacturer: TELEMECANIQUE
Type: Thermal Overload Relay
Model: LRD163
Alternative Model: LRD

Short Name: LR2D
Rated Operational Voltage: 690 V AC
Rated Operational Current: 10 A
Rated Insulation Voltage: 690 V
Frequency: 50 … 60 Hz
Sitting Range: 9 … 13 A
Rated Impulse Voltage (Uimp): 6 kV
Number of Poles: 3-Pole
Auxiliary Contact: 1 Normally Open (NO) + 1 Normally Closed (NC)
Protection Class: IP20
Ambient Temperature: -20 … 60 °C
Dimensions: 93 x 45 x 72 mm
