Manufacturer: Schneider / Telemecanique

Type: Inductive Sensor

Model: XS506B1PBM8

Sensor Design: Cylindrical

Detector Flush Mounting Acceptance: Flush mountable

Material: Stainless steel

Nominal Sensing Distance: 1.5 mm

Discrete Output Function: 1 NC

Discrete Output Type: PNP

Electrical Connection: 3 pins M8 male connector

Rated Supply Voltage: 12 … 24 VDC

Switching Capacity: <= 200 mA
Degree of Protection: IP67

Ambient Air Temperature for Operation: -25 … 70 °C

Diameter, Length: 6.5 mm, 42 mm

Weight: 0.03 Kg
