Manufacturer:  TELEMECANIQUE SCHNEIDER

Type:  Photoelectric Sensor

Series Name: General PURPOSE Single Mode

Model: XUB2BPBWM12R

Emission: Infrared Thru Beam Sensor Receiver

Nominal Sensing Distance: 15 m

Operating Voltage: 12 … 24 V DC

Switching Capacity: <= 100 mA
Discrete Output Type: PNP

Discrete Output Function: Normally Closed

No-Load Supply Current: 35 mA

Maximum Voltage Drop: < 1.5 V
Switching Frequency: <= 500 Hz
Line of Sight Type: 90° Lateral

Sensor Design: Cylindrical M18

Electrical Connection: Male Connector M12, 4-Pin

Diameter, Length: 18, 76 mm

Degree of Protection: IP65

Ambient Operating Temperature: -25 … 55 °C

Housing Material: Metal

Enclosure Material: Nickel Plated Brass

Weight: 0.03 kg
