Telemecanique ZCK-M1H29 Limit Switch Body

The Telemecanique ZCKM1H29 Limit Switch Body is a durable and precise component designed for reliable position detection in industrial automation systems. Featuring a robust metal housing and IP66 protection, it provides dependable performance even in harsh operating environments.

Manufacturer: Telemecanique
Type: Limit Switch Body
Model: ZCK-M1H29
Alternative Models: XCK-M

Technical Information

• Rated Operational Voltage AC-15: 240 V AC
• Rated Operational Current AC-15: 3 A
• Rated Impulse Voltage (Uimp): 6 kV
• Rated Thermal Current: 10 A
• Rated Insulation Voltage (Ui): 500 V
• Contact: 2-Pole, 1 Normally Open (NO) + 1 Normally Closed (NC)
• Material: Metal
• Protection Class: IP66
• Ambient Temperature: -10 / 120 °C
• Dimensions: 64 x 64 x 36 mm
