Manufacturer: TELEMECANIQUE
Type: Limit Switch
Device short name: ZCKS
Product compatibility: XCKS
Model: ZCK-S1

Output Configuration: 1 NC + 1 NO
Contact Operation: Snap action
Switching Voltage max.: 240 V AC, 250 V DC
Contact Current max.: 3 A AC, 0.27 A DC
Connection: Cable entry, Screw-clamp terminals, clamping capacity: 1 x 0.34…2 x 1.5 mm²
Protection Class: IP65
Ambient Operating Temperature: -25 … 70 °C
Dimensions: 40 X 73 X 36 mm
