Manufacture: Tesch
Type: Safety Relay
Model: F121X01
Art No.: 07400041

Rated voltage: 230 V AC
Frequency: 50/60 Hz
Power consumption: 4 W
Switching capacity:
AC-15: 250 V AC,6 A
DC-13: 24 V DC,3 A
Output contact: 3 N/O Safety ,1 N/C Auxiliary
Ambient Temperature max.: –5 … 55 °C
Switch material: Ag SN O2+ 0.5µ Au
Protection degree: Terminals IP 20, IP 40 casing
Dimensions: 55 x 75 x 109.5 mm
