Trans Link UCT206 Take-Up Ball Bearing Unit
The Trans Link UCT206 Take-Up Ball Bearing Unit is a high-performance solution designed for industrial applications. Engineered with precision, it features the T 206 housing and UC 206 bearing, ensuring durability and consistent performance in demanding environments.
Manufacturer: Trans Link
Type: TAKE UP BALL BEARING UNIT
Model: UCT206
Technical Information:
- Housing No.: T 206
- Bearing No.: UC 206
- Shaft Diameter: 30 mm
- Width of Inner Ring: 38.1 mm
- Width of Piloting Groove: 12 mm
- Overall Height: 102 mm
- Height of Attachment End: 56 mm
- Overall Length: 113 mm
- Diameter of Attachment Bolt Hole: 22 mm
Perfect for industrial systems requiring precision and reliability, the Trans Link UCT206 Take-Up Ball Bearing Unit offers excellent alignment and robust performance for a wide range of applications.
