Manufacturer: VEGA
Type: Hydraulic Block Cylinder
Model: CE10020PISACN
Piston Diameter: 100 mm
Rod Diameter: 45 mm
Stroke: 25 mm
Cylinder Shape: Rectangle
Mode of operation: Double-Acting
Maximum operating pressure: 150 bar
Piston rod thread: Female
Temperature range: 0 …. 100 °C
Connection: G 1/2”
Weight: 10.9 kg
