Vega SWING61.XXGBVXPCX Vibrating Level Switch
The Vega SWING61.XXGBVXPCX is a robust vibrating level switch designed for reliable detection of liquid levels across a wide range of industrial applications. With stainless steel wetted parts, high protection rating, and flexible process fittings, it ensures long-lasting performance even under extreme temperature and pressure conditions.
Manufacturer: Vega
Type: Vibrating Level Switch
Model: SWING61.XXGBVXPCX
Order No.: 0000000/000
Technical information
- Electronics: C
- Current Max.: 400 mA
- Power Supply: 20“250 V AC/DC
- Wetted Parts: Stainless steel
- Process Fitting: GBV; Threads from G¾, ¾ NPT, flanges from DN 25, 1³, hygienic fittings
- Electronics Type: Transistor Output, NAMUR version
- Density: 0.7 / 2.5 g/cm³
- Plug Connector: M12X1
- Protection: IP66/67
- Process Pressure: -1 / 64 bar
- Process Temperature: -50 / +250 °C
