Manufacturer: Vegatrenn/ Vega
Type: Double channel Ex separator
Model: TRENN1420013
Part No: SB1608-0-0-1-3
Layout: 2.62279-0-0-1
Series: VEGATRENN142

Operating Voltage: 20 … 35 V DC
Max. Power Consumption: 5 W
Number of sensors: 2 x 4 … 20 mA/HART (5 x HART multidrop per channel)
Terminal voltage: 21 … 16.5 V DC at 4 … 20 mA
Ambient Temperature: -20 … 60 °C
Protection Degree: IP20
Dimension: 111 X 20 X 113 mm
