WAIRCOM ULCSV/R11050 Direct Acting Single Solenoid Valve
The WAIRCOM ULCSV/R11050 is a compact and reliable 3/2-way direct acting solenoid valve designed for precise control of compressed air systems. Engineered for continuous operation and stable performance, it is ideal for industrial automation, pneumatic circuits, and applications requiring accurate switching and fast response times.
Manufacturer: WAIRCOM
Type: Direct acting Single Solenoid Valve
Model: ULCSV/R11050
Code: VA17-10
Series: UL
Technical Information
- Fluid: Air
- Valve Function: 3/2 Way
- Type of Actuation: Electrical
- Max. Pressure: 10 bar
- Flow Rate @ 6 bar: 80 NI/m
- Pneumatic Connection: G1/8
- Duty: 100 percent ED
- Supply Voltage: 110 V AC, 50/60 Hz
- Working temperature: 0 / +50 °C
- Nominal diameter: 2 mm
Recommendation
This model is highly recommended for users who need a durable, fast-acting valve that performs consistently under continuous duty cycles. Its compact UL-series design allows easy installation in tight pneumatic panels, while the 3/2-way configuration makes it suitable for cylinder control, air signaling, and small automation modules. Ideal for OEM machines, pneumatic distributors, and precision air control systems.
